Smart design for compact spaces
CORSET37 is a series of versatile casement windows designed for optimal functionality and elegant aesthetics. Featuring a robust hinged system with a sleek 30mm frame depth, these units are crafted from premium 6063-T6 aluminum alloy for exceptional durability and performance. The system accommodates both inward and outward openings with side-hung and top-hung configurations, offering design flexibility for various architectural needs. Compatible with 4-8 mm (only openable) glazing and featuring a 1.52 mm profile thickness, CORSET37 combines practicality and space- efficient design to enhance utility areas and compact spaces, in any architectural project.
• Casement system designed specially for high-rise and mass housing projects
• Maintaining durability and performance
• Supports glass thickness from 5mm to 24mm for versatile application requirements
• Available with both single locking and multi-point locking options based on project needs
• Engineered for efficient fabrication, faster installation, and large-scale production applications
GLAZING
Minimum
5 mm
Maximum
24 mm
Frame Specifications
Single Frame 40 | 50 mm
Double Frame 50 | 112 mm
Sash 65 | 80 | 100 mm
Profile thickness
Up to 1.5 mm
Maximum weight per leaf
120 Kg
Permittable dimensions per leaf (W X H)
900 X 2400
Transmittance
*Please consult typology, dimensions & glass
Maximum acoustic insulation
Wind resistance
Air permeability
Water tightness
Opening Possibilities
*Consult maximum weight and dimensions according to typologies
