EPIC19

EPIC19

Ultra-Slim Luxury, Seamless Living

GREFET EPIC19-series premium system aluminium sliding window is modular designed for ultra-slim-with-views. Designed to balance structural integrity with maximize natural light at a slim 19mm sightline and is comprised from high-strength 6063-T6 alloy. Its fully flushed outer frame and unitized sash with structurally bonded glass promises clean, uninterrupted visuals. Thanks to best-in-segment sound insulation, accessibility through an option of water-drainage systems ensuring next-gen aluminium sliding windows system well-suited for fine architecture: EPIC19 is perfect for luxury homes and commercial spaces alike.

• Best-in-class minimal concept unitised sliding system design
• Ultra-slim 19 mm central interlock for maximum transparency
• Designed for expansive views and larger openings
• Supports tall shutter heights with superior stability
• Reinforced interlock for enhanced structural strength
• Floating 90° corner opening for seamless panoramic views
• Advanced unitised silicone bonding system
• Hidden handle design for a clean minimalist appearance
• Premium slim aesthetics with maximum glass visibility
• Ideal for luxury villas, facades, and modern architecture

GLAZING
Minimum

12 mm

Maximum
26 mm
Possible Typology
2, 3, 4, 6 leaf
Frame Specifications
2 track 104 mm
3 track 163 mm
Frame depth
34 - 45 - 45 mm
SASH
41 - 58 mm
Profile thickness
2 to 5 mm
Maximum weight per leaf
400 Kg
Central interlocking
19 mm
Multi-locking system with key option
Yes
Permittable dimensions per leaf (W X H)
1800 X 4250
